TVS Radeon
₹58,850 – ₹80,600
- Brand
- TVS
- Type
- Bike
- Fuel
- Petrol
- Engine
- 109.7 cc
- Mileage
- 73.68 km/l
- Launched
- 01 Aug 2018
TVS Radeon variants
TVS Radeon Base Edition BS6 specifications
| Mileage | 73.68 km/l |
|---|---|
| Front brake | Drum |
| Rear brake | Drum |
| Fuel capacity | 10 L |
| Body type | Commuter Bike |
| City mileage | 73.68 km/l |
|---|---|
| Highway mileage | 68.6 km/l |
| Engine type | Singel cylinder, 4 Stroke, Fuel Injecation, Air cooled Spark Ignition Engine |
|---|---|
| Displacement | 109.7 cc |
| Max torque | 8.7 Nm @ 4500 rpm |
| Number of cylinders | 1 |
| Cooling system | Air Cooled |
| Starting | Kick and Self Start |
| Fuel supply | Fuel Injection |
| Clutch | Wet, multiple type |
| Gear box | 4 Speed |
| Emission type | bs6-2.0 |
| Compression ratio | 10.0 : 1 |
| Ignition | ECU |
| ABS | Synchronized Braking System |
|---|---|
| Speedometer | Analogue |
| Tripmeter | Analogue |
| Tachometer | Analogue |
| LED tail light | Yes |
| Odometer | Analogue |
| Fuel gauge | Analogue |
| Instrument console | Analogue |
| Seat type | Single |
| Body graphics | Yes |
| Passenger footrest | Yes |
| Additional features of variant | Pillion Grabrail With Carrier, Unbreakable Turn Signal Mounting, Full Chrome Metal Exhaust, High Performance Dura Grip Tyres |
| Pass switch | Yes |
|---|---|
| Engine kill switch | Yes |
| Additional features | Pillion Grabrail With Carrier, Unbreakable Turn Signal Mounting, Full Chrome Metal Exhaust, High Performance Dura Grip Tyres |
| Width | 705 mm |
|---|---|
| Length | 2025 mm |
| Height | 1080 mm |
| Fuel capacity | 10 L |
| Ground clearance | 180 mm |
| Wheelbase | 1265 mm |
| Kerb weight | 113 kg |
| Fuel reserve | 1.5 L |
| Saddle height | 780 |
| Headlight | LED |
|---|---|
| Tail light | LED |
| Turn signal lamp | Bulb |
| LED tail lights | Yes |
| Low fuel indicator | Yes |
| Dr ls | Yes |
| Front brake diameter | 130 mm |
|---|---|
| Rear brake diameter | 110 mm |
| Front suspension | Telescopic oil damped shock absorber |
| Rear suspension | 5 step adjustable hydraulic shock absorber |
| Peak power | 8.19 PS @ 7350 rpm |
|---|---|
| Drive type | Chain Drive |
| Transmission | Manual |
| Battery capacity | 12V / 4AH |
| Suspension front | Telescopic oil damped shock absorber |
|---|---|
| Suspension rear | 5 step adjustable hydraulic shock absorber with arm |
| Brakes front | Drum |
| Brakes rear | Drum |
| Tyre size | Front :-2.75-18, Rear :- 3.00-18 |
| Wheel size | Front :-457.2 mm, Rear :-457.2 mm |
| Wheel type | Alloy |
| Tubeless tyre | Tubeless |
| Charging at home | No |
|---|---|
| Charging at charging station | No |
