TVS Jupiter
₹74,125 – ₹89,825
- Brand
- TVS
- Type
- Scooter
- Fuel
- Petrol
- Engine
- 113.3 cc
- Mileage
- 61.2 km/l
- Launched
- 01 Sep 2013
TVS Jupiter variants
TVS Jupiter Drum specifications
| Mileage | 61.2 km/l |
|---|---|
| Front brake | Drum |
| Rear brake | Drum |
| Fuel capacity | 5.1 L |
| Body type | Scooty |
| Overall mileage | 61.2 km/l |
|---|
| Engine type | Single cylinder, 4 stroke, fuel injection, air cooled, spark ignition engine |
|---|---|
| Displacement | 113.3 cc |
| Max torque | 9.2 Nm @ 5000 rpm |
| Number of cylinders | 1 |
| Cooling system | Air Cooled |
| Valve per cylinder | 2 |
| Starting | Kick and Self Start |
| Fuel supply | Fuel Injection |
| Clutch | Dry - Centrifugal clutch |
| Gear box | CVT |
| Emission type | bs6-2.0 |
| Compression ratio | 10.5 ± 0.3 : 1 |
| Ignition | ECU - Controlled Ignition |
| ABS | Synchronized Braking System |
|---|---|
| Speedometer | Analogue |
| Tripmeter | Digital |
| Tachometer | Digital |
| LED tail light | Yes |
| Odometer | Analogue |
| Fuel gauge | Analogue |
| Instrument console | Analogue |
| Seat type | Single |
| Passenger footrest | Yes |
| Additional features of variant | Emergency Brake Warning, Front Fuel Filling |
| Pass switch | Yes |
|---|---|
| Engine kill switch | Yes |
| Display | Yes |
| Riding modes | Eco,Power |
| Additional features | Emergency Brake Warning, Front Fuel Filling |
| Width | 665 mm |
|---|---|
| Length | 1848 mm |
| Height | 1158 mm |
| Fuel capacity | 5.1 L |
| Ground clearance | 163 mm |
| Wheelbase | 1275 mm |
| Kerb weight | 106 kg |
| Saddle height | 790 |
| Headlight | LED |
|---|---|
| Tail light | LED |
| Turn signal lamp | Bulb |
| LED tail lights | Yes |
| Low fuel indicator | Yes |
| Dr ls | Yes |
| Front brake diameter | 130 mm |
|---|---|
| Rear brake diameter | 130 mm |
| Radial tyre | Yes |
| Front suspension | Telescopic Hydraulic |
| Rear suspension | Twin tube emulsion type shock absorber with 3 step adjustment |
| Peak power | 8.02 PS @ 6500 rpm |
|---|---|
| Drive type | Belt Drive |
| Transmission | Automatic |
| Battery capacity | 12V / 4AH |
| Suspension front | Telescopic Hydraulic |
|---|---|
| Suspension rear | Twin tube emulsion type shock absorber with 3-step adjustment. |
| Brakes front | Drum |
| Brakes rear | Drum |
| Tyre size | Front :- 90/90 - 12, Rear :- 90/90 - 12 |
| Wheel size | Front :-304.8 mm,Rear :-304.8 mm |
| Wheel type | Sheet Metal |
| Tubeless tyre | Tubeless |
| Charging at home | No |
|---|---|
| Charging at charging station | No |
